Compression Load Cell

XJCSENSensor specializes in manufacturing and customizing industrial-grade all-size force sensors and instrumentation, including multi-axis force sensors, load cells, torque sensors, tension, and pressure sensors, etc. We deliver tailored force control system solutions based on strain gauge, capacitive, MEMS, and piezoelectric technologies to meet diverse application requirements.

Compression Load Cell

Automotive, medical, robot, electronic, mechanical equipment, automation equipment, etc.
Force measurement in small space installation, such as feeling tester for keyboard switch, compression force measurement for hot and cold lamination machine, and grasping force measurement for foot grippers.

unfold

Compression load cell X-C Series

Compression load cell X-L Series

Compression load cell X-CS Series

Compression load cell X-B Series

Compression load cell X-X Series

Compression load cell X-C Series

learn more

Compression load cell X-L Series

learn more

Compression load cell X-CS Series

learn more

Compression load cell X-B Series

learn more

Compression load cell X-X Series

learn more

Compression Load Cell

Adopts high-precision resistance strain principle.
Supports force measurement in the range of 0-100kg.
Robust pressure-bearing structure with simplified installation.
Small size, beautiful appearance.
High response frequency, high-precision.

Find Sensor :

显示 15 个产品


	X-X09
	X-X08
	X-C02-3M
	X-BW23
	X-B78
	X-X02
	X-C01-10
	X-C01-20-4M
	X-C01-08
	X-C18
	X-CS-U9
	X-B-D152-H12
	X-C01-6.5
	X-CS10-2M-H12-KL
	X-L11-D70
	X-L11-55
	X-B77-G
	X-B-D150
	X-CS15-I-H9-2M
	X-C08-H30

Model	Description	Capacity	Diameter Roll	Material	SPEC SHEETS
X-X09	Compression Load Cell	0.5t, 1t, 2t, 5t	212mm	Stainless Steel,Alloy Steel	view more
X-X08	Compression Load Cell	0.3t, 0.5t, 1t, 2t	130mm	Stainless Steel,Alloy Steel	view more
X-C02-3M	Compression Load Cell	5kg,10kg, 20kg, 50kg,100kg, 200kg, 500kg,1t, 2t, 5t, 10t, 12t	Mutiple	Alloy SteelStainless Steel	view more
X-BW23	Compression Load Cell	5kg,10kg,20kg,50kg,100kg,200kg,300kg,500kg	28mm	Alloy Steel	view more
X-B78	Compression Load Cell	20t	760mm	Alloy Steel	view more
X-X02	Compression Load Cell	0.3kg, 1kg, 2kg, 3kg, 5kg, 10kg	70mm	Aluminum Alloy	view more
X-C01-10	Compression Load Cell	3kg, 5kg, 10kg, 20kg, 30kg, 50kg, 100kg	10mm	Stainless Steel	view more
X-C01-20-4M	Compression Load Cell	10kg, 20kg, 50kg, 100kg, 200kg, 300kg, 500kg, 1000kg	20mm	Stainless Steel	view more
X-C01-08	Compression Load Cell	3kg, 5kg, 10kg, 20kg, 30kg, 50kg, 100kg	8mm	Stainless Steel	view more
X-C18	Compression Load Cell	5kg, 10kg, 20kg, 50kg, 100kg, 200kg, 500kg, 1t, 2t, 5t	41mm	Stainless Steel	view more
X-CS-U9	Compression Load Cell	1t, 2t, 5t	60mm	Alloy Steel	view more
X-B-D152-H12	Compression Load Cell	20kg, 50kg, 100kg, 200kg, 200kg, 1t	152mm	Alloy Steel, Aluminum Alloy	view more
X-C01-6.5	Compression Load Cell	5kg, 10kg, 20kg, 30kg, 50kg	6.5mm	Stainless Steel	view more
X-CS10-2M-H12-KL	Compression Load Cell	2kg, 3kg, 5kg	12mm	Stainless Steel	view more
X-L11-D70	Compression Load Cell	50kg, 100kg, 200kg, 500kg, 1t, 2t	70mm	Alloy Steel	view more
X-L11-55	Compression Load Cell	50kg, 100kg, 200kg, 500kg, 1t, 2t	55mm	Alloy Steel	view more
X-B77-G	Compression Load Cell	30t	370mm	Alloy Steel	view more
X-B-D150	Compression Load Cell	5t, 10t, 15t, 20t	300mm	Alloy Steel	view more
X-CS15-I-H9-2M	Compression Load Cell	2kg, 3kg, 5kg, 10kg, 20kg	15mm	Stainless Steel	view more
X-C08-H30	Compression Load Cell	5kg, 10kg, 20kg, 50kg, 100kg, 300kg, 500kg	38mm	Stainless Steel	view more
